应用程序范例 ¶

Here’s the class definition:

class MainWindow(QMainWindow):
    def __init__(self, parent=None):
        self.textEdit = QPlainTextEdit()
        self.curFile = ""
        # ...
    def loadFile(self, fileName):
        pass
    def closeEvent(self, event):
        pass
    def newFile(self):
        pass
    def open(self):
        pass
    def save(self):
        pass
    def saveAs(self):
        pass
    def about(self):
        pass
    def documentWasModified(self):
        pass
    # Enable this only if QT_NO_SESSIONMANAGER is not defined
    # def commitData(self):
    #   pass
    def createActions(self):
        pass
    def createStatusBar(self):
        pass
    def readSettings(self):
        pass
    def writeSettings(self):
        pass
    def maybeSave(self):
        pass
    def saveFile(self, fileName):
        pass
    def setCurrentFile(self, fileName):
        pass
    def strippedName(self, fullFileName):
        pass


The public API is restricted to the constructor. In the protected section, we reimplement closeEvent() to detect when the user attempts to close the window, and warn the user about unsaved changes. In the private slots section, we declare slots that correspond to menu entries, as well as a mysterious documentWasModified() slot. Finally, in the private section of the class, we have various members that will be explained in due time.

from PySide2.QtCore import Qt, QFile, QFileInfo, QSettings, QTextStream
from PySide2.QtGui import QIcon
from PySide2.Widgets import (QAction, QApplication, QFileDialog, QMainWindow,
                             QPlainTextEdit, QFileDialog, QMessageBox, )


We start by including <QtWidgets> , a header file that contains the definition of all classes in the Qt Core, Qt GUI and Qt Widgets modules. This saves us from the trouble of having to include every class individually. We also include mainwindow.h .

You might wonder why we don’t include <QtWidgets> in mainwindow.h and be done with it. The reason is that including such a large header from another header file can rapidly degrade performances. Here, it wouldn’t do any harm, but it’s still generally a good idea to include only the header files that are strictly necessary from another header file.

def __init__(self, parent=None):
    QMainWindow.__init__(self)
    self.textEdit =  QPlainTextEdit()
    self.setCentralWidget(textEdit)
    self.createActions()
    self.createMenus()
    self.createToolBars()
    self.createStatusBar()
    self.readSettings()
    self.textEdit.document().contentsChanged.connect(self.documentWasModified)
    self.setCurrentFile("")
    self.setUnifiedTitleAndToolBarOnMac(True)


In the constructor, we start by creating a QPlainTextEdit widget as a child of the main window (the this object). Then we call setCentralWidget() to tell that this is going to be the widget that occupies the central area of the main window, between the toolbars and the status bar.

Then we call createActions() and createStatusBar() , two private functions that set up the user interface. After that, we call readSettings() to restore the user’s preferences.

We establish a signal-slot connection between the QPlainTextEdit ‘s document object and our documentWasModified() slot. Whenever the user modifies the text in the QPlainTextEdit , we want to update the title bar to show that the file was modified.

At the end, we set the window title using the private setCurrentFile() function. We’ll come back to this later.

def closeEvent(self, event):
    if maybeSave():
        writeSettings()
        event.accept()
    else:
        event.ignore()


When the user attempts to close the window, we call the private function maybeSave() to give the user the possibility to save pending changes. The function returns true if the user wants the application to close; otherwise, it returns false. In the first case, we save the user’s preferences to disk and accept the close event; in the second case, we ignore the close event, meaning that the application will stay up and running as if nothing happened.

def File(self):
    if maybeSave():
        textEdit.clear()
        setCurrentFile("")


newFile() slot is invoked when the user selects File|New from the menu. We call maybeSave() to save any pending changes and if the user accepts to go on, we clear the QPlainTextEdit and call the private function setCurrentFile() to update the window title and clear the windowModified 标志。

def open(self):
    if maybeSave():
        fileName = QFileDialog.getOpenFileName(self)
        if not fileName.isEmpty():
            loadFile(fileName)


open() slot is invoked when the user clicks File|Open. We pop up a QFileDialog asking the user to choose a file. If the user chooses a file (i.e., fileName is not an empty string), we call the private function loadFile() to actually load the file.

def save(self):
    if curFile.isEmpty():
        return saveAs()
    else:
        return saveFile(curFile)


save() slot is invoked when the user clicks File|Save. If the user hasn’t provided a name for the file yet, we call saveAs() ; otherwise, we call the private function saveFile() to actually save the file.

def saveAs(self):
    fileName = QFileDialog.getSaveFileName(self)
    if fileName.isEmpty():
        return False
    return saveFile(fileName)


在 saveAs() , we start by popping up a QFileDialog asking the user to provide a name. If the user clicks Cancel, the returned file name is empty, and we do nothing.

def about(self):
   QMessageBox.about(self, tr("About Application"),
            tr("The <b>Application</b> example demonstrates how to "
               "write modern GUI applications using Qt, with a menu bar, "
               "toolbars, and a status bar."))


The application’s About box is done using one statement, using the about() static function and relying on its support for an HTML subset.

tr() call around the literal string marks the string for translation. It is a good habit to call tr() on all user-visible strings, in case you later decide to translate your application to other languages. The Internationalization with Qt overview covers tr() in more detail.

def documentWasModified(self):
    setWindowModified(textEdit.document().isModified())


documentWasModified() slot is invoked each time the text in the QPlainTextEdit changes because of user edits. We call setWindowModified() to make the title bar show that the file was modified. How this is done varies on each platform.

def MainWindow.createActions(self):
    Act = QAction(QIcon(":/images/new.png"), tr("&New"), self)
    Act.setShortcuts(QKeySequence.New)
    Act.setStatusTip(tr("Create a new file"))
    Act.triggered.connect(newFile)
    openAct = QAction(QIcon(":/images/open.png"), tr("&Open..."), self)
    openAct.setShortcuts(QKeySequence.Open)
    openAct.setStatusTip(tr("Open an existing file"))
    openAct.triggered.connect(open)
    ...
    aboutQtAct =  QAction(tr("About &Qt"), self)
    aboutQtAct.setStatusTip(tr("Show the Qt library's About box"))
    aboutQtAct.triggered.connect(qApp.aboutQt)


createActions() private function, which is called from the MainWindow constructor, creates QAction s and populates the menus and two toolbars. The code is very repetitive, so we show only the actions corresponding to File|New, File|Open, and Help|About Qt.

A QAction is an object that represents one user action, such as saving a file or invoking a dialog. An action can be put in a QMenu 或 QToolBar , or both, or in any other widget that reimplements actionEvent() .

An action has a text that is shown in the menu, an icon, a shortcut key, a tooltip, a status tip (shown in the status bar), a “What’s This?” text, and more. It emits a triggered() signal whenever the user invokes the action (e.g., by clicking the associated menu item or toolbar button).

Instances of QAction can be created by passing a parent QObject or by using one of the convenience functions of QMenu , QMenuBar or QToolBar . We create the actions that are in a menu as well as in a toolbar parented on the window to prevent ownership issues. For actions that are only in the menu, we use the convenience function addAction() , which allows us to pass text, icon and the target object and its slot member function.

Creating toolbars is very similar to creating menus. The same actions that we put in the menus can be reused in the toolbars. After creating the action, we add it to the toolbar using addAction() .

The code above contains one more idiom that must be explained. For some of the actions, we specify an icon as a QIcon 到 QAction constructor. We use fromTheme() to obtain the correct standard icon from the underlying window system. If that fails due to the platform not supporting it, we pass a file name as fallback. Here, the file name starts with : . Such file names aren’t ordinary file names, but rather path in the executable’s stored resources. We’ll come back to this when we review the application.qrc file that’s part of the project.

    cutAct.setEnabled(False)
    copyAct.setEnabled(False)
    textEdit.copyAvailable[bool].connect(cutAct.setEnabled)
    textEdit.copyAvailable[bool].connect(copyAct.setEnabled)
}


The Edit|Cut and Edit|Copy actions must be available only when the QPlainTextEdit contains selected text. We disable them by default and connect the copyAvailable() signal to the setEnabled() slot, ensuring that the actions are disabled when the text editor has no selection.

Just before we create the Help menu, we call addSeparator() . This has no effect for most widget styles (e.g., Windows and macOS styles), but for some styles this makes sure that Help is pushed to the right side of the menu bar.

def createStatusBar(self):
    statusBar().showMessage(tr("Ready"))


statusBar() returns a pointer to the main window’s QStatusBar widget. Like with menuBar() , the widget is automatically created the first time the function is called.

def readSettings(self):
    settings("Trolltech", "Application Example")
    pos = settings.value("pos", QPoint(200, 200)).toPoint()
    size = settings.value("size", QSize(400, 400)).toSize()
    resize(size)
    move(pos)


readSettings() function is called from the constructor to load the user’s preferences and other application settings. The QSettings class provides a high-level interface for storing settings permanently on disk. On Windows, it uses the (in)famous Windows registry; on macOS, it uses the native XML-based CFPreferences API; on Unix/X11, it uses text files.

QSettings constructor takes arguments that identify your company and the name of the product. This ensures that the settings for different applications are kept separately.

使用 value() to extract the value of the geometry setting. The second argument to value() is optional and specifies a default value for the setting if there exists none. This value is used the first time the application is run.

使用 saveGeometry() and Widget::restoreGeometry() to save the position. They use an opaque QByteArray to store screen number, geometry and window state.

def writeSettings(self):
    settings = QSettings("Trolltech", "Application Example")
    settings.setValue("pos", pos())
    settings.setValue("size", size())


writeSettings() function is called from closeEvent() . Writing settings is similar to reading them, except simpler. The arguments to the QSettings constructor must be the same as in readSettings() .

def maybeSave(self):
    if textEdit.document()->isModified():
        ret = QMessageBox.warning(self, tr("Application"),
                                  tr("The document has been modified.\n"
                                     "Do you want to save your changes?"),
                                 QMessageBox.Save | QMessageBox.Discard | QMessageBox.Cancel)
        if ret == QMessageBox.Save:
            return save()
        elif ret == QMessageBox.Cancel:
            return False
    return True


maybeSave() function is called to save pending changes. If there are pending changes, it pops up a QMessageBox giving the user to save the document. The options are Yes , No ，和 Cancel . The Yes button is made the default button (the button that is invoked when the user presses Return) using the 默认 flag; the Cancel button is made the escape button (the button that is invoked when the user presses Esc) using the Escape 标志。

maybeSave() function returns true in all cases, except when the user clicks Cancel or saving the file fails. The caller must check the return value and stop whatever it was doing if the return value is false .

def loadFile(self, fileName):
    file = QFile(fileName)
    if !file.open(QFile.ReadOnly | QFile.Text):
        QMessageBox.warning(self, tr("Application"), tr("Cannot read file "
            "{}:\n{}.".format(fileName, file.errorString())))
        return
    in = QTextStream(file)
    QApplication.setOverrideCursor(Qt::WaitCursor)
    textEdit.setPlainText(in.readAll())
    QApplication.restoreOverrideCursor()
    self.setCurrentFile(fileName)
    self.statusBar().showMessage(tr("File loaded"), 2000)


在 loadFile() , we use QFile and QTextStream to read in the data. The QFile object provides access to the bytes stored in a file.

We start by opening the file in read-only mode. The 文本 flag indicates that the file is a text file, not a binary file. On Unix and macOS, this makes no difference, but on Windows, it ensures that the “\r\n” end-of-line sequence is converted to “\n” when reading.

If we successfully opened the file, we use a QTextStream object to read in the data. QTextStream automatically converts the 8-bit data into a Unicode QString and supports various encodings. If no encoding is specified, QTextStream assumes the file is written using the system’s default 8-bit encoding (for example, Latin-1; see codecForLocale() 了解细节)。

Since the call to readAll() might take some time, we set the cursor to be WaitCursor for the entire application while it goes on.

At the end, we call the private setCurrentFile() function, which we’ll cover in a moment, and we display the string “File loaded” in the status bar for 2 seconds (2000 milliseconds).

def saveFile(self, fileName):
    file = QFile(fileName)
    if !file.open(QFile.WriteOnly | QFile::Text):
        QMessageBox.warning(self, tr("Application"),
                             tr("Cannot write file %1:\n%2.")
                             .arg(fileName)
                             .arg(file.errorString()))
        return False
    out = QTextStream(file)
    QApplication.setOverrideCursor(Qt.WaitCursor)
    out << textEdit.toPlainText()
    QApplication.restoreOverrideCursor()
    setCurrentFile(fileName)
    statusBar().showMessage(tr("File saved"), 2000)
    return True


Saving a file is similar to loading one. We use QSaveFile to ensure all data are safely written and existing files are not damaged should writing fail. We use the 文本 flag to make sure that on Windows, “\n” is converted into “\r\n” to conform to the Windows convention.

def setCurrentFile(fileName):
    curFile = fileName
    textEdit.document().setModified(False)
    setWindowModified(False)
    if curFile.isEmpty():
        shownName = "untitled.txt"
    else:
        shownName = strippedName(curFile)
    setWindowTitle(tr("%1[*] - %2").arg(shownName).arg(tr("Application")))


setCurrentFile() function is called to reset the state of a few variables when a file is loaded or saved, or when the user starts editing a new file (in which case fileName is empty). We update the curFile variable, clear the modified flag and the associated QWidget:windowModified flag, and update the window title to contain the new file name (or untitled.txt ).

strippedName() function call around curFile 在 setWindowTitle() call shortens the file name to exclude the path. Here’s the function:

def strippedName(self, fullFileName):
    return QFileInfo(fullFileName).fileName()


main() function for this application is typical of applications that contain one main window:

#include <QApplication>
#include <QCommandLineParser>
#include <QCommandLineOption>
#include "mainwindow.h"
int main(int argc, char *argv[])
{
    Q_INIT_RESOURCE(application);
#ifdef Q_OS_ANDROID
    QApplication::setAttribute(Qt::AA_EnableHighDpiScaling);
#endif
    QApplication app(argc, argv);
    QCoreApplication::setOrganizationName("QtProject");
    QCoreApplication::setApplicationName("Application Example");
    QCoreApplication::setApplicationVersion(QT_VERSION_STR);
    QCommandLineParser parser;
    parser.setApplicationDescription(QCoreApplication::applicationName());
    parser.addHelpOption();
    parser.addVersionOption();
    parser.addPositionalArgument("file", "The file to open.");
    parser.process(app);
    MainWindow mainWin;
    if (!parser.positionalArguments().isEmpty())
        mainWin.loadFile(parser.positionalArguments().first());
    mainWin.show();
    return app.exec();
}


The main function uses QCommandLineParser to check whether some file argument was passed to the application and loads it via MainWindow::loadFile().

As you will probably recall, for some of the actions, we specified icons with file names starting with : and mentioned that such file names aren’t ordinary file names, but path in the executable’s stored resources. These resources are compiled

The resources associated with an application are specified in a .qrc file, an XML-based file format that lists files on the disk. Here’s the application.qrc file that’s used by the Application example:

<Code snippet "/tmp/snapshot-qt5full-5.15.0/qt5/qtbase/mainwindows/application/application.qrc" not found>


.png files listed in the application.qrc file are files that are part of the Application example’s source tree. Paths are relative to the directory where the application.qrc file is located (the mainwindows/application 目录)。

The resource file must be mentioned in the application.pro file so that qmake knows about it:

<Code snippet "mainwindows/application/application.pro:0" not found>


qmake will produce make rules to generate a file called qrc_application.cpp that is linked into the application. This file contains all the data for the images and other resources as static C++ arrays of compressed binary data. See Qt 资源系统 for more information about resources.
